AKUSENSE
PTZ-R400N-C
PTZ-R400N-C
Regular price
€48,10 EUR
Regular price
Sale price
€48,10 EUR
Unit price
/
per
Couldn't load pickup availability
Share
| Model | PTZ-R400N-C |
| Category | Photoelectric Sensor |
| Detection Range | 10~4000mm |
| Housing Style | Square |
| Light Source | Red LED |
| Optical Working Principle | Retroreflective |
| Output Mode | NPN Open collector |
| Sensor Type | IO-Link Type |
| Spot size | Φ 280 4 mm/m |
| Accessories | There is no |
| Ambient Light | Incandescent lamp ≤5000 Lux; Sun exposure ≤ 50,000 Lux |
| Connection Method | 2M/3 core cable |
| Current consumed | ≤20mA |
| Detected Object | - |
| Dimensions | 11.0 x31.0 x20.0 mm |
| Hysteresis | — |
| Indicator Light | Output function: Orange LED, Operating status: Green LED |
| Insulation Resistance | ≥50MΩ (500VDC) between power terminal and housing |
| Load Current | ≤100mA (30VDC) |
| Material | ABS |
| Maximum Tightening Torque | 0.5 Nm or less |
| Operating Humidity | 35~85%RH (no condensation) |
| Operating Temperature | -25~55℃(without freezing) |
| Operating Voltage | 10~30V DC |
| Protection Circuit | Power supply reverse polarity protection/surge protection/short circuit protection |
| Protection Rating | IP67 |
| Repeatability | — |
| Residual Voltage | < 2.0V (100mA) |
| Response time | 0.5ms |
| Sensitivity Adjustment | Single-turn potentiometer |
| Storage humidity | 35 to 95%RH (no condensation) |
| Storage temperature | -30℃~+70℃(without freezing) |
| Switching frequency | 4kHz |
| Switch mode | L.on (light entry action) /D.on (light blocking action) can be switched |
| Vibration Resistance | 10~50Hz, double amplitude 1.5mm, 2 hours in each direction X, Y and Z |
| Weight | 0.05 kg |
| Withstand Voltage | 1000VAC (50/60Hz), 1 minute between the power terminal and housing |
