AKUSENSE
PTE-TEM10PR
PTE-TEM10PR
Regular price
€19,48 EUR
Regular price
Sale price
€19,48 EUR
Unit price
/
per
Couldn't load pickup availability
Share
| Model | PTE-TEM10PR |
| Category | Photoelectric Sensor |
| Detection Range | 10000mm (fix) |
| Housing Style | Square |
| Light Source | Infrared light LED |
| Optical Working Principle | Through-beam |
| Output Mode | PNP open collector |
| Sensor Type | Square Type |
| Spot size | At 1m: 4cm * 4cm |
| Accessories | Bracket, screws |
| Ambient Light | LED light ≤10000 Lux |
| Connection Method | 2M/ 4-core cable |
| Current consumed | ≤120mA |
| Detected Object | Phi is 60 mm |
| Dimensions | 20.0 x31.0 x11.0 mm |
| Hysteresis | — |
| Indicator Light | Working indicator light: green; Action light: red |
| Insulation Resistance | ±1000V 50/60Hz 60s |
| Load Current | 15mA |
| Material | PC |
| Maximum Tightening Torque | 0.5 Nm or less |
| Operating Humidity | 35 to 90%RH (no condensation) |
| Operating Temperature | -15~55℃(without freezing) |
| Operating Voltage | 10~30V DC |
| Protection Circuit | Reverse polarity protection/short circuit protection |
| Protection Rating | IP67 |
| Repeatability | — |
| Residual Voltage | < 1.5V |
| Response time | ≤3.4ms |
| Sensitivity Adjustment | None |
| Storage humidity | 35~95%RH |
| Storage temperature | -30~+70℃ |
| Switching frequency | 150Hz |
| Switch mode | L.on (light entry action) /D.on (light blocking action) can be switched |
| Vibration Resistance | 10~50Hz, 0.5mm amplitude, 2 hours in each direction X, Y and Z |
| Weight | 0.05 kg |
| Withstand Voltage | 1000VAC (50/60Hz) |
