AKUSENSE
PTE-DV100PR
PTE-DV100PR
Regular price
€15,52 EUR
Regular price
Sale price
€15,52 EUR
Unit price
/
per
Couldn't load pickup availability
Share
| Model | PTE-DV100PR |
| Category | Photoelectric Sensor |
| Detection Range | 1~1000mm |
| Housing Style | Square |
| Light Source | Infrared light LED 940nm |
| Optical Working Principle | Diffuse Reflection |
| Output Mode | PNP open collector |
| Sensor Type | Square Type |
| Spot size | At 50cm: 1.8cm by 1.6cm |
| Accessories | Screwdriver |
| Ambient Light | Incandescent lamp ≤3000 Lux; Sunlight exposure ≤ 10,000 Lux |
| Connection Method | 2M/ 4-core cable 4mm diameter |
| Current consumed | ≤25mA |
| Detected Object | ≤5mm |
| Dimensions | 20.0 x31.0 x11.0 mm |
| Hysteresis | ＜15%Sr |
| Indicator Light | Working indicator light: green; Action light: red |
| Insulation Resistance | 20 m Ω |
| Load Current | 100mA |
| Material | PBT+ fiberglass |
| Maximum Tightening Torque | 0.1 Nm or less |
| Operating Humidity | 35~85%RH (no condensation) |
| Operating Temperature | -25~55℃(without freezing) |
| Operating Voltage | 10~30V DC |
| Protection Circuit | Reverse polarity protection/surge protection/short circuit protection |
| Protection Rating | IP67 |
| Repeatability | ≤5%SN |
| Residual Voltage | < 1.5V |
| Response time | ≤1.6ms |
| Sensitivity Adjustment | 6 turns potentiometer |
| Storage humidity | 35~95%RH |
| Storage temperature | -30~+70℃ |
| Switching frequency | 300Hz |
| Switch mode | L.on (light entry action) /D.on (light blocking action) can be switched |
| Vibration Resistance | 10~55Hz sweep frequency, 1.5mm amplitude, X, Y, Z three directions for 2 hours each |
| Weight | 0.05 kg |
| Withstand Voltage | ≤0.1mA (1000V AC) |
