AKUSENSE
KUM08-0307P
KUM08-0307P
Regular price
€391,03 EUR
Regular price
Sale price
€391,03 EUR
Unit price
/
per
Couldn't load pickup availability
Share
| Model | KUM08-0307P |
| Category | Label Detection Sensor |
| Housing style | U-shaped fork |
| Slot depth | 69mm |
| Slot width | 3.2mm |
| Connection method | M8/4-pin plug |
| Detecting object | 2mm minimum label gap |
| Dimensions | 85.5x47.3x18.2mm |
| Environmental illumination | Unavailable |
| Hysteresis | — |
| Indicator light | Output function: Red LED, operational status: Green LED |
| Insulation resistance | DC500V insulation resistance >50MΩ |
| Light source | Ultrasonic |
| Load current | ≤100mA |
| Material | Aluminum |
| Operating humidity | 35~95%RH(no condensation) |
| Operating temperature | -5~55℃ |
| Operating voltage | 12~24V DC±10% |
| Optical working principle | Through-beam |
| Output mode | PNP collector open |
| Power consumption | ≤45mA |
| Protection circuit | short-circuit protection |
| Protection rating | IP65 |
| Repeat accuracy | ±0.2 |
| Residual voltage | <2V@1L=100mA |
| Response time | 0.3ms |
| Storage humidity | 35~95%RH(no condensation) |
| Storage temperature | -20~70℃ |
| Switching frequency | 1.5kHz |
| Switching mode | L.on (light-on action)/D.on (dark-on action) switchable |
| Vibration resistance | 10~50Hz, amplitude 1.5mm, 2 hours each in X/Y/Z axes |
| Weight | 0.019kg |
| Withstand voltage | Insulation voltage of VC100V when current <0.1mA |
| Working principle | Ultrasonic detection |
