AKUSENSE
ESB-BV30P
ESB-BV30P
Regular price
€15,09 EUR
Regular price
Sale price
€15,09 EUR
Unit price
/
per
Couldn't load pickup availability
Share
| Model | ESB-BV30P |
| Category | Photoelectric Sensor |
| Detection Range | 1~300mm |
| Housing Style | Square |
| Light Source | Infrared LED 940nm (modulated) |
| Optical Working Principle | Background suppression diffuse reflection |
| Output Mode | PNP open collector |
| Sensor Type | BGS Type (ESB Series) |
| Spot size | Ø 8 mm / 300 mm |
| Accessories | Screwdriver |
| Ambient Light | Incandescent lamp ≤3000 Lux; Sunlight exposure ≤ 10,000 Lux |
| Connection Method | 2m/ 4-core cable |
| Current consumed | ≤25mA |
| Detected Object | ≤5mm |
| Dimensions | 11.0 x20.0 x31.0 mm |
| Hysteresis | — |
| Indicator Light | Output function: red LED, running status: green LED |
| Insulation Resistance | 20 m Ω |
| Load Current | ≤100mA (30VDC) |
| Material | ABS with fiberglass |
| Maximum Tightening Torque | 0.5 Nm or less |
| Operating Humidity | 35~85%RH (no condensation) |
| Operating Temperature | -25~55℃(without freezing) |
| Operating Voltage | 10~30V DC |
| Protection Circuit | Reverse polarity protection/surge protection/short circuit protection |
| Protection Rating | IP65 |
| Repeatability | ≤5% |
| Residual Voltage | 1.5 V or less |
| Response time | 1ms |
| Sensitivity Adjustment | 6 turns potentiometer |
| Storage humidity | 35~95%RH |
| Storage temperature | -30~+70℃ |
| Switching frequency | 2kHz |
| Switch mode | L.on (light entry action) /D.on (light blocking action) can be switched |
| Vibration Resistance | 10~50Hz, 0.5mm amplitude, 2 hours in each direction X, Y and Z |
| Weight | 0.049 kg |
| Withstand Voltage | ≤0.1mA (1000V AC) |
