AKUSENSE
MLD25-50PV
MLD25-50PV
Normál ár
€147,07 EUR
Normál ár
Akciós ár
€147,07 EUR
Egységár
/
/
Nem sikerült betölteni az átvehetőségi adatokat
Share
| Model | MLD25-50PV |
| Category | Triangulation Measuring Sensor |
| Communication protocol | Modbus RTU |
| Housing | Square |
| Measuring range | 35-65mm |
| Optical working principle | Diffuse reflection |
| Output Mode | Switching quantity (PNP)/analog quantity (voltage 0~5V/ current 4~20mA) /RS-485 output |
| Reference distance | 50mm |
| Working principle | Triangulation |
| Accessories | Cable |
| Ambient illumination | Sunlight: ≤10000 lux without interference; Incandescent lamp: ≤3000 lux |
| Communication mode | - |
| Connection type | 7 core composite cable, 2m long |
| Controls the output | - |
| Control the input | - |
| Current consumption | < 65mA at 12V, < 40mA at 24V |
| Data output rate | - |
| Dielectric strength | < 0.1mA (when 1000V AC) |
| Dimension | 20x28x45mm |
| Enclosure rating | IP67 |
| Expandable number | - |
| Input voltage | - |
| Insulation sesistance | > 500MΩ (500V DC) |
| Light source | Red semiconductor laser wavelength: 655nm 1mW Class2 |
| Linearity | ±0.1% F.S. |
| Load current | ≤100mA |
| Material | Body shell: die-cast aluminum; Front cover: acrylic base |
| Measure force | - |
| Number of sensors that can be connected | - |
| Operating humidity | 35~85%RH (no condensation) |
| Operating temperature | -10~+45℃(without freezing) |
| Operating voltage | 12~24V DC±10% |
| Output voltage | - |
| Power consumption | - |
| Precision | - |
| Protection circuit | Power supply reverse polarity protection/short circuit protection/overload protection/surge protection |
| Repeatability | 30um |
| Resolution | - |
| Response time | < 10ms/5ms/1.5ms |
| Sampling frequency | - |
| Spot size | Φ 50 microns |
| Switching mode | L.on/D.on mode/key /RS-485 switch |
| Temperature drift characteristics | 0.03%/℃ F.S. |
| Use pressure range | - |
| Vibration resistance | 10~55Hz sweep frequency, 1.5mm amplitude, X, Y, Z three directions for 2 hours each |
| Weight | 90g |
| Working mode | - |
